In this mode the device is controlled via a DMX controller.
Press [MENU] to open the main menu.
Press [MENU] repeatedly or press [UP] and [DOWN] to select the ‘dNH’ menu item and conrm
with [ENTER].
The display shows ‘d001’ ; press [ENTER]. Use [UP] and [DOWN] to select a DMX mode: 2-
channel ( ‘02Ch’ ) or 9-channel ( ‘09Ch’ ) and conrm with [ENTER]. Now you can set the number
of the rst DMX channel to be used by the device (DMX address). Use [UP] and [DOWN] to
select a value between 001 and 511 (display shows ‘001’ … ‘511’ ). Conrm with [ENTER].
Make sure that this number matches the conguration of your DMX controller. The following
table shows the highest possible DMX address for the various DMX modes.
Mode Highest possible DMX address
2-channel 511
9-channel 504
To return to the main menu without making changes, press [MENU].
DMX operating mode
