Machine Overview
Unit
Accessories
22
23
Filters
2
3
1
21
22
Telescopic extension tube
Pre-motor lter
23 Post motor lter
1
14
4
5
6
7
8
9
10
11
12
13
15
16
17
18
19
17
21
1 Handle
2 Handle height adjuster
3 Upper handle release button
4 Dirt bin release button
5 Carry handle
6 Power on/o button
7 Brushbar on/o button
8 Inner cyclones
9 Dirt bin
10 Post motor lter release button
11 Brushbar blockage indicator
12 Brushbar access clips
13 Rotating brushbar
14 Hose to extension tube connector
15 Quick release cord wrap
16 Cord
17 3-in-1 crevice, upholstery & dusting
brush tool
18 Wheels
19 Hose to machine connector
20 Brushbar reset button
20
24
24 Turbo tool
25 Extension hose
(VARU1200 model only)
