Machine Overview
10
11
12
13
15
16
23
19
20
21
22
17
14
9d
9c
9b
Tool storage
NOTE: Items 10-17 are stored
onboard at the rear of the unit.
18
9a
9e
5
6
7
4
8 1 2 3
Carry handle
Water tank lid
On/off button
Steam ready (green LED)
Water heating (orange LED)
Variable steam dial
Hose inlet
Tool storage (hidden)
Steam handle and hose
a) Extension tube release
b) Safety latch (hidden)
c) Steam trigger
d) Detergent tank cap
e) Detergent control dial (hidden)
Metal brush
Detail nozzle
Small plastic brush
Large plastic brush
Scraper tool
Concentration nozzle
Window squeegee/upholstery tool
Velcro microfibre pad (x1)
Floor head
Measuring jug
Funnel
3pc extension tubes
Upholstery tool cloth (x2)
Carpet glider
