WIRING DIAGRAM LEGEND
RL= Unit C/ autoleveller GICAR
Mv= Micro vacuum tank H
2
O
0/I= Metallic lever switch on/off line
IV= Metallic lever switch steam activation
K1C= Bimetallic thermostat coffee boiler resistance
K2C= Bimetallic thermostat coffee boiler resistance
K3V= Bimetallic thermostat steam tank resistance
K4V= Bimetallic thermostat steam tank resistance
EVC= Solenoid valve for H
2
O filling
P= Vibration pump ULKA c/ bimetallic protection TH
LV= Spy d=5 steam
LRC= Spy d=5 coffee resistance
L0/I= Spy d=5 line ON
RC= Coffee resistance
RV= Steam resistance
mGr= Micro group coffee
Sliv= Level probe
S = Level mass
X= Line conector 2V P/M fastin/on
THC= Bulb thermostate for coffee resistance
PR= Pressure switch mater c/micro
