VBOX 3i - Page 112

Connector 4 - D IN (Lemo 3 PIN)
PIN I/O Function Range
1 I Ground
2 I
Digital Input 2. Logging
on/off
0 – 5 V (14 V tolerant)
3 I
Digital Input 1. Brake
Trigger
0 – 5 V (14 V tolerant)
