04 - VB3i LED Indicators
SATS
• Flashing red indicates no satellites in view
• Flashing green sequence indicates the number of GPS satellites currently being tracked. Each flash indicates a
satellite with a short pause between each sequence.
• Flashing orange sequence indicates the number of GLONASS Satellites currently being tracked. Each flash
indicates a satellite with a short pause between each sequence.
Sequence showing 1 Satellite
Sequence showing 4 Satellites
Sequence showing 0 Satellites
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_3i_Range/VBOX_3i_User_Guide_(All_Variants)/04_-
_VB3i_LED_Indicators
19
