RMS Channels
These four channels are for diagnostic purposes only and cannot be turned on or off. They show the noise which is
present on the vertical and horizontal speed channels, as calculated by the VB3i GPS engine.
The RMS (root mean square) channels which will be logged are listed below.
RMS_HPOS RMS_VPOS RMS_HVEL RMS_VVEL
T1 channel
Internal debug channel logged when IMU Filter is running.
