GNSS antennas require a ground plane to operate correctly. This helps to reduce unwanted reflections of the GNSS
signal caused by nearby objects, and usually the metal roof of a vehicle performs this function. However, if a test
requires an antenna to be placed either off the vehicle, or on a vehicle that does not have a metallic roof, a special
ground plane antenna must be used. This has an internal ground plane and can operate perfectly without the need for
mounting on a metal surface. Ground plane antennas are available from your VBOX distributor.
