Dual Antenna Systems
For further info on slip/pitch and slip/roll setups, click here.
When testing using dual antenna mode, the greater the antenna separation, the greater the accuracy of the dual
antenna derived data channels.
Slip Angle Accuracy Pitch/Roll Angle Accuracy
<0.2° rms at 0.5 m antenna separation
<0.1° rms at 1.0 m antenna separation
<0.067° rms at 1.5 m antenna separation
<0.05° rms at 2.0 m antenna separation
<0.04° rms at 2.5 m antenna separation
<0.14° rms at 0.5 m antenna separation
<0.07° rms at 1.0 m antenna separation
<0.047° rms at 1.5 m antenna separation
<0.035° rms at 2.0 m antenna separation
<0.028° rms at 2.5 m antenna separation
