PIN In / Out Description Range

8 I Isolated Channel 4 -

1.8 M Ohms input

impedance

9 - 10 N/C

11 O 1PPS Output -IMU04

12 O RS232 TxD -IMU04

13 I RS232 RxD -IMU04

14 O Vbatt

Equal to Input Voltage.

300 mA

15 O GND Ground

16 O 5 V Out Isolated 5 V ±2%. 120 mA

17 O GND Ground

18 O ISO-GND Isolated Ground

19-25 N/C
