VDG TM100B25 - Table of Contents

Table of Contents
Installation Instructions................................... 2
Electrical Connection .................................... 2
Drum Motor with Sprockets (STM) Assembly Procedure......... 3
Connection Diagrams:
Single Voltage - Three Phase.......................... 4
Dual Voltage - Three Phase (Star/Delta) ................. 4
Dual Voltage - Three Phase (240/480 volts) .............. 5
Single Phase (110 volts).............................. 5
Single Phase (220 volts) ............................. 6
Three Phase with Brake (RTM) ........................ 6
Three Phase (240 volts) with Brake (RTM) ............... 7
Three Phase (480 volts) with Brake (RTM) ............... 7
Connecting a Drum Motor Equipped with a
Backstop (TB) Device.................................... 8
Releasing & Engaging a Drum Motor Equipped with a
Manual Release Backstop (MRB) Device .................... 9
Oil Change Instructions ................................. 10
Drum Motor Oil Content .............................. 11 - 12
Oil Types ............................................ 13
Troubleshooting ....................................... 14
