Setting output resolution
27.3. After opening processor press Setup key to enter setup menu, press Brt- to
select 1.Output Image, press OK to enter output image setup;
27.4. After entering output image setup menu, press Brt- key to select 1.2
Resolution, rotate OK to select 1920 x 1080_60, then press OK to enter
confirmation menu press OK to confirm (every processor must do the step
and every processor must set same output resolution);
Setting splicing (Mosaic)
27.5. First the processor must select DVI source as input, then press Mosaic key to
Input： HDMI
In Status： 1080p
--------------------------------------------------------------------
Output Size： 1920 x 1080
Output Start： ( 0, 0 )
--------------------------------------------------------------------
Switch Mode： One Key SW.
Switch Time： 0 Sec
Setup
--------------------------------------------------------------------
1. Output Image >>
2. Input Video Signal >>
3. Text Overlay >>
4. Color & Brightness, etc. >>
5. Audio >>
6. Communication >>
7. 语言主/ Language >>
8. Advanced >>
10. Output Image
--------------------------------------------------------------------
1.2 Resolution 1920 x 1080_60 ?
1.2 Out Width 1920
1.3 Out Height 1080
1.4 Out H_Start 0
1.5 Out V_Start 0
1.6 Test Pattern Off
Tips
--------------------------------------------------------------------
Data will reset
Press < OK > to reset
Press < OK > to reset
