5.2 PIP/PBP operation
LVP615U allows to insert PIP window on the current display signal.
That is dual image display function(PIP/PBP)
。
PIP signal can be any
input signal from other input groups or current input signal itself.
（
signal group refer to page 19signal group list
）
Dual image size can
be preset 3 modes.The detailed operation method is as follow：
Enter PIP/PBP mode： press On/Off button，the indicator will
be on. LVP615U enters PIP/PBP mode. Then press input signal button
to select PIP signal. At the same time, LCD will display main input and
pip input status and size.
（
as shown below
）
Main Input： HDMI
Main In Status： 1080p_60Hz
PIP Input： V1
PIP In Status： PAL
--------------------------------------
Main Output Size： 1920x1080
Main Output Start： （0，0）
PIP Output Size： 640x320
PIP Output Start： （16，16）
Select PIP input signal
：
In PIP mode
，
press button to select
corresponding signal. Then this signal is configured as PIP input.
Select Main input signal ： Press On/Off button to close PIP
mode.
，
Press button to select corresponding signal as main input
signal. Then press On/Off button to enter PIP mode to select pip
signal again.
