6.2 Input video signal setting
Press Setup button to enter setup menu. Press↓ button to select 2.
Input video signal and press OK to enter this item.
2.Input video signal
--------------------------------------
2.1 DVI EDID 1280x1024_60
2.2 V1/V2 backup off
2.3 VGA1/VGA2 backup off
2.4 HDMI/DVI backup off
2.5 V2 or YPbPr V2
2.6 Switch mode one key switch
6.2.1 DVI EDID
LVP615U supports custom DVI EDID. In concert with “custom
output format” ， LVP615U can realize DVI input image and output
image pixel to pixel display. LVP615U supports 16 fixed DVI EDID and
custom EDID. Normally the parameters setting should be consistent
with“custom output format”
（
refer to page28 ).
Operation steps
：
In the menu 2.1 DVI EDID
，
rotate knob to
select suitable resolution and press OK to save data. After save data,
need press OK to enter“2.1 custom DVI EDID” menu to set
2.1.1custom width、2.1.2custom height and 2.1.3 custom V frequency
and press ↓ to enter APPLY and press “OK” to make parameters
effective.
