Vdwall LVP615U - PIP;PBP and Mosaic Configuration

LVP615U 使用说明
46
6.9 PIP/PBP setting
D.PIP/PBP Mode=M1
--------------------------------------
D.1 PIP Width 640
D.2 PIP Height 320
D.3 PIP H_Start 16
D.4 PIP V_Start 16
D.5 MAIN Width 1920
D.6 MAIN height 1080
D.7 MAIN H_Start 0
D.8 MAIN V_Start 0
The setup option is used to set LVP615U’s three user defined PIP/PBP mode.
Operation as below:
When LVP615U’s PIP/PBP status is open (the indicator light on “On/Off” button
is lit up), press Setup button, LVP615U enters “D. PIP/PBP” menu. Then press
