2.1custom DVI EDID
--------------------------------------
2.1.1 Cus. width 1920
2.1.2 Cus. height 1002
2.1.3 Cus. V Freq. 60
2.1.4 Apply OK to apply
6.2.2 Hot spare setting
LVP615U supports hot spare of input signals. When the current
input signal is lost. LVP615U will switch to the spare signal
automatically to avoid image interruption caused by the fault of signal
source.
2.Input video signal
--------------------------------------
2.1 DVI EDID 1280x1024_60
2.2 V1/V2 backup off
2.3 VGA1/VGA2 backup off
2.4 HDMI/DVI backup off
2.5 V2 or YPbPr V2
2.6 switch mode one key switch
As shown in the above table，if ”2.2 V1/V2 backup on”, if V1
signal is lost, processor will switch to V2 automatically.
6.2.3 V2 or YPbPr selection
V2 and YPbPr of LVP615U share the same port and button. Need
configure. Default input is V2. If need YPbPr input, then need set this
