Veeder-Root TLS-350 PLUS - Viewing PMC Reports Via RS-232 Connection

Operation PMC Status Report
PMC Status Report
Figure 7. PMC Status Report
Viewing PMC Reports Via RS-232 Connection
CONNECTING LAPTOP TO CONSOLE
Connect your laptop to the TLS console’s RS-232 or Multiport module using one of the methods shown in the
examples in Figure 8 below.
VP OVER PRESSURE TEST
STATUS: 0.4'' WC PASS
PMC VERSION 01.00
PRESS <STEP> TO CONTINUE
MMM:DD, YYYY HH:MM:SS XM
ALL FUNCTIONS NORMAL
S
S
S
S
EFFLUENT EMISSIONS TEST
STATUS: PASS
S
VP DUTY CYCLE TEST
STATUS: PASS
pmc\fig7.eps
Prints out a copy of the
PMC Status report.
See example at right.
C
F
P
S
T
Change
E Enter
Function
Print
M Mode
Step
Tank/Sensor
Key press
sequence
Repress until
desired message
appears in display
Key Legend
1
2
PMC STATUS
----------------------
PMC VERSION: 01.00
VP OVER PRESSURE TEST
STATUS: 0.4”WC PASS
EFFLUENT EMISSIONS TEST
0.000 LB/1KG PASS
VP DUTY CYCLE TEST
STATUS: 0.00% PASS
P
F
PMC STATUS
PRESS <STEP> TO CONTINUE
Section 16
Pressure Management Control
16-10
