Veeder-Root TLS-450 - Figure 6. Remove AC Channel Cover

Replacing the Power Supply (P/N 330020-623) Before Turning Off Power
9
4. Remove the two #8 taptite screws from the AC Channel cover and put the cover and screws aside (see
Figure 6).
Figure 6. Remove AC Channel cover
Legend for numbered boxes in Figure 6
956-8.eps
1
2
2
1. AC Channel cover
2. #8 taptite screws (2)
