Veeder-Root TLS-450PLUS Module Replacement Instructions

Console Module Locations Console Comm Modules
6
Console Comm Modules
Table 3 lists optional comm modules, their permissible slots in the comm bay and the configurable (C) and non-
configurable (NC) ports for each module in each slot.
Slots 4 (Ethernet module) and 5 (USB module) are fixed and are unavailable for user-selectable Comm modules.
Table 3. User Selectable Comm Module Permissible Slots and Port Availability
Comm Module
Comm
Type
Slot 1 Slot 2 Slot 3
Port Port Port
12 1 212
RS-232 Single Port (also EDIM, Satellite S-SAT and
Satellite H-JBox apps.)
Serial
NC C NC C NC C
RS-232 Dual Port (also EDIM, Satellite S-SAT and
Satellite H-JBox apps.)
CC C CNCC
RS-485 Single Port NC C NC C NC C
RS-485 Dual Port C C C C NC C
RS-232/RS-485 Dual Port
C
(RS-232)
C
(RS-485)
C
(RS-232)
C
(RS-485)NC
C
(RS-485)
SiteFax / Modem NC C NC C NC C
CDIM
DIM
C NC C NC ---- ----
IFSF LON C NC C NC C NC
