Veepeak OBDCheck VP39 - Page 16

- 14 -
= = = = = = = = = = =1/3
Control Module
Engine
Module $A4
Exit
►
• Use the SCROLL button to select a module, and press ENTER/EXIT button.
2) Wait a few seconds while the code reader validates the PID MAP.
= = = = = = = = = = = = =
I/M Readiness
Reading PID...
- Please Wait -
3) If the vehicle supports both types of tests, then both types shows on the screen for
selection.
= = = = = = = = = = = =1/3
I/M Readiness
Since DTCs Cleared
This Drive Cycle
Exit
►
4) Use SCROLL button to view the status of the MIL light (“ON” or “OFF”) and the
following monitors:
• Misre monitor -- Misre monitor
• Fuel System Mon -- Fuel System Monitor
• Comp. Component -- Comprehensive Components Monitor
• EGR -- EGR System Monitor
• Oxygen Sens Mon -- O2 Sensors Monitor
• Catalyst Mon -- Catalyst Monitor
• EVAP System Mon -- Evaporative System Monitor
• Oxygen Sens htr --O2 Sensor Heater Monitor
• Sec Air System -- Secondary Air Monitor
• Htd Catalyst -- Heated Catalyst Monitor
• A/C Refrig Mon -- A/C system Monitor
= = = = = = = = = = = =1/3
Since DTCs Cleared
MIL Status OFF
Misre Monitor OK
Fuel System Mon. OK
Comp. Component OK
