If a linearisation curve is selected, the measuring signal is no
longer compulsorily linear proportional to the level. This must
be taken into consideration by the user, particularly when
adjusting the switching point on the level switch.
In the menu item "Sensor-TAG" you can edit a twelve-digit
measurement loop name. An unambiguous designation can be
thus assigned to the sensor, e.g. the measurement loop name
or the tank or product designation. In digital systems and in the
documentation of larger plants, a singular designation should
be entered for exact identification of individual measuring
sites.
The characters comprise:
l Letters from A … Z
l Numbers from 0 … 9
l Special characters +,-,/,-
Factory setting is "Sensor".
Sensor-TAG
Sensor
Menu section, display
An integrated background lighting can be switched via the
adjustment menu. The following version is necessary:
l Indicating and adjustment module …- 01 or higher
l Sensor electronics 4 … 20 mA …- 01 or higher
l Sensor electronics pressure transmitter 4 … 20 mA …- 02
or higher
l Sensor electronics Profibus PA or Foundation Fieldbus …-
03 or higher
The version is stated on the type label of the indicating and
adjustment module or the sensor electronics. The function
depends also on the height of the supply voltage, see
operating instructions manual of the respective sensor.
Information:
For instruments with national approvals such as e.g. according
to FM and CSA, this function only available at a later date.
In the default setting, the lightning is deactivated.
Edit sensor TAG
Lighting
14 Indicating and adjustment module PLICSCOM
Setup
27835-EN-070123
