2 Scope
VEGAFLEX 80 series • Two-wire 4 … 20 mA/HART
42960-EN-170410
2 Scope
2.1 Instrument version
This safety manual applies to TDR sensors
VEGAFLEX 81, 82, 83, 86
Electronics types:
•
Two-wire 4 … 20 mA/HART with SIL qualication
•
Two-wire 4 … 20 mA/HART with SIL qualication and supplemen-
tary electronics "Additional current output 4 … 20 mA"
Valid versions:
•
from HW Ver 1.0.0
•
from SW Ver 1.0.0
Probe types:
•
Only original probes of VEGA Grieshaber KG must be used!
For versions with Ex-d-ia/XP-AIS approval the separe safety-related
characteristics are valid (see chapter Safety-related characteristics)!
Corresponding type code: VEGAFLEX FX8*(*).*D/I/V/P****A*****
2.2 Area of application
The transmitter can be used in a safety-related system according to
IEC 61508 in the modes low demand mode or high demand mode for
the measurement of the following process variables:
•
Point level detection
•
Level measurement in liquids and bulk solids
•
Interface measurement in liquids
Due to the systematic capability SC3 this is possible up to:
•
SIL2 in single-channel architecture
•
SIL3 in multiple channel architecture
The following interface can be used to output the measured value:
•
Current output: 4 … 20 mA
The following interfaces are only permitted for parameter adjustment
and for informative use:
•
HART
®
•
Display and adjustment module PLICSCOM
•
VEGACONNECT
•
Current output II
1)
2.3 SIL conformity
The SIL conformity was independently judged and certied by the
TÜV Rheinland according to IEC 61508:2010 (Ed.2).
2)
1)
Only with instrument version with supplementary electronics "Additional cur-
rent output 4 … 20 mA".
2)
Verication documents see appendix.
