6.3 Menu schematic
Information:
Depending on the version and application, the highlighted menu
windows are not always available.
Device settings
▶ Device settings
Measurement loop
Display
Diagnostics
Service
Info
Device-TAG
Device Name
Host name IP address
Fix IP address
▼
LAN/Internet
IP address:
192.168.200.200
Subnet mask:
255.255.255.0
Change?
Time/Date
15:34
18.09.2004
Communication protocol
VEGA protocol
▼
WRA
Enable?
Measurement loop - Input
Device settings
▶ Measurement loop
Display
Diagnostics
Service
Info
Measurement loop
▶ Input
Measured variable
Operation
Damping
Linearisation curve
Input ①
VEGAPULS (addr. 1)
Distance
Change input?
Sensor info ①
Display now?
Sensor setting ①
Start sensor setting?
VEGAMET 624 • 4 … 20 mA/HART signal conditioning instrument 25
