Velodyne EQ-Max Series User Manual

WWW.VELODYNE.COM
18 - EQ-Max Series User’s Manual
SPECIFICATIONS
Model EQ-MAX-8 EQ-MAX-10 EQ-MAX-12 EQ-MAX-15
Woofer 8” (20.3 cm) forward firing
(6.3” piston diameter)
10” (20.3 cm) forward firing
(8.2” piston diameter)
12” (20.3 cm) forward firing
(9.7” piston diameter)
15” (20.3 cm) forward firing
(12.7” piston diameter)
Amplifier: Class D 360 watts Dynamic/
180 watts RMS Power
390 watts Dynamic/
195 watts RMS Power
450 watts Dynamic/
225 watts RMS Power
1500 watts Dynamic/
750 watts RMS Power
Cabinet Design Extended Excursion
Down-firing port
Extended Excursion
Down-firing port
Extended Excursion
Down-firing port
Extended Excursion
Down-firing port
Frequency Response
Overall
(+/-3 dB)
17 - 240 Hz
32 - 120 Hz
16 - 240 Hz
28 - 120 Hz
14.6 - 240 Hz
25 - 120 Hz
14 - 240 Hz
23 - 120 Hz
Voice Coil 2” 2-Layer copper 2” 2-Layer copper 2” 2-Layer copper 2.5” 4-Layer copper
Cone Reinforced fiber Reinforced fiber Reinforced fiber Reinforced fiber
Magne 4.66 lbs 5.36 lbs 7.4 lbs 10.14 lbs
High-Pass Crossover 80 Hz*, 6 dB/octave 80 Hz*, 6 dB/octave 80 Hz*, 6 dB/octave 80 Hz*, 6 dB/octave
Low-Pass Crossover 40 - 135 Hz adjustable
(12 dB octave, 24 dB ultimate)
40 - 135 Hz adjustable
(12 dB octave, 24 dB ultimate)
40 - 135 Hz adjustable
(12 dB octave, 24 dB ultimate)
40 - 135 Hz adjustable
(12 dB octave, 24 dB ultimate)
Outputs Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Input Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Gold plated line-level
Nickel plated speaker level
Digital Phase 0, 90, 180, 270 degrees 0, 90, 180, 270 degrees 0, 90, 180, 270 degrees 0, 90, 180, 270 degrees
Auto On/Off Yes Yes Yes Yes
Removable Grill Yes Yes Yes Yes
LED Display Yes Yes Yes Yes
Accessories Mic, mic stand, remote control Mic, mic stand, remote control Mic, mic stand, remote control Mic, mic stand, remote control
Cabinet (H,W,D) (cm) with
grille
14.5” x 13.25” x 14.875”
(36.8 x 33.7 x 37.8 cm)
16.75” x 15.25” x 17”
(42.5 x 38.7 x 43.1 cm)
17.875” x 16.375” x 18”
(45.4 x 41.6 x 45.7 cm)
21.5” x 19” x 21”
(54.6 x 48.3 x 53.3 cm)
Warranty (parts/labor) (North
America)
Three years (electronics)
Five years (drivers)
Three years (electronics)
Five years (drivers)
Three years (electronics)
Five years (drivers)
Three years (electronics)
Five years (drivers)
Shipping Weight (approx.) 44 lbs. (20 Kg) 55 lbs. (25 Kg) 61 lbs. (28 Kg) 75 lbs. (34 Kg)
* Note: Varying speaker and amplier input load impedances may cause the high-pass crossover frequency to
slightly vary.
Specications are subject to change without notice.

Velodyne EQ-Max Series Specifications

General

Enclosure Type	Bass Reflex
Auto On/Off	Yes
Driver Size	12 inch
Inputs	Line-Level
Outputs	Line-Level
Phase	0 or 180 degrees
