Vemer HT NiPt Series User Manual

- 45 -
User Manual Digital Heat Regulators
English
(21) If the parameter is set to “yes”, a mobile average is taken of 8 measurement
values (4 seconds approx.). If “no”, this average is not calculated
[SNS] sensor menu
Notes:
(22) the range of sensors and the default sensor depend on the model.
All the sensors used are listed below:
NiPt thermal resistance
Type of sensor Display message
Pt100 (*) PtE (*)
Ni100 nI
* The instrument is set to this parameter by default.
NTC thermal resistances
Type of sensor Display message
(**) nt0
(**) nt1
type 4 nt2 (*)
(**) CSt
* The instrument is set to this parameter by default.
It corresponds to the use of temperature sensor NTC code VN870200
(see “Red Line” catalogue under the item Heat Regulation-Temperature Probes)
** For the use of sensors other than “type 4” listed above (see note *), it is possible
to select one of the three items “nt0, nt1, CSt”, corresponding to probes
with different temperature/resistance ratios.
To identify the type of sensor to be selected in these cases, we recommend
contacting our Technical Assistance Service directly
Labels of
parameters that
can be modified
Description
Parameter
values
default
notes
TY0 Sensor type 0 - 0 16 (22)
TY1 Sensor type 1 - 12 16 (23)
GFA Cold joint correction enable - no yes yes (24)
S01 Display of sensor 0 or 1 - S0 S1 S0 (23)
min max
unit
- 44 -
User Manual Digital Heat Regulators
English
[ALR] alarm menu
Notes:
(13) This is the status taken on by the outputs in probe alarm condition (see note 11)
(14) This value is added to or subtracted from the set point defined for the maximum
or minimum alarm respectively
(15) If “yes”, the acoustic signal of the key and the buzzer are enabled in alarm
condition. If “no”, both of these are disabled.
(16) If “yes”, the type of alarm is also displayed during its timing.
If “no”, the type of alarm is displayed only at the end of the timing
[DSP] display menu
Notes:
(17) Parameter active only if the operating mode permits
(18) This value is added to the measurement to compensate for imprecision
(19) This is the resolution at which the measurement is displayed:
0.1 if “HI” or 1.0 if “LO”
(20) Important: if the measurement unit is modified, the parameters set are not con
verted automatically, but have to be re-calibrated.
Labels of
parameters that
can be modified
Description
Parameter
values
default
notes
SUA Output status in probe
alarm condition - 0 3 0 (13)
LOA Minimum alarm shift degrees 0.1 100 50 (14)
HIA Maximum alarm shift degrees 0.1 100 50 (14)
DFA Alarm differential degrees 0.1 100 2
TRA Alarm activation delay time min 0 200 0
SOU Buzzer enable - no yes no (15)
EAC Alarm message in timing enable - no yes no (16)
min max
unit
Labels of
parameters that
can be modified
Description
Parameter
values
default
notes
LO1 Lower limit of set-point 1 degrees -99 HI1 -99
HI1 Upper limit of set-point 1 degrees LO1 999 999
LO2 Lower limit of set-point 2 degrees -99 HI2 -99 (17)
HI2 Upper limit of set-point 2 degrees LO2 999 999 (17)
SOF Probe calibration offset degrees -50 +50 0.0 (18)
RIS Resolution displayed - HI LO HI (19)
UNI Temperature measurement - C F C (20)
FIL Measurement filter - no yes yes (21)
min max
unit
