Vemer HT NiPt Series User Manual

- 44 -
User Manual Digital Heat Regulators
English
[ALR] alarm menu
Notes:
(13) This is the status taken on by the outputs in probe alarm condition (see note 11)
(14) This value is added to or subtracted from the set point defined for the maximum
or minimum alarm respectively
(15) If “yes”, the acoustic signal of the key and the buzzer are enabled in alarm
condition. If “no”, both of these are disabled.
(16) If “yes”, the type of alarm is also displayed during its timing.
If “no”, the type of alarm is displayed only at the end of the timing
[DSP] display menu
Notes:
(17) Parameter active only if the operating mode permits
(18) This value is added to the measurement to compensate for imprecision
(19) This is the resolution at which the measurement is displayed:
0.1 if “HI” or 1.0 if “LO”
(20) Important: if the measurement unit is modified, the parameters set are not con
verted automatically, but have to be re-calibrated.
Labels of
parameters that
can be modified
Description
Parameter
values
default
notes
SUA Output status in probe
alarm condition - 0 3 0 (13)
LOA Minimum alarm shift degrees 0.1 100 50 (14)
HIA Maximum alarm shift degrees 0.1 100 50 (14)
DFA Alarm differential degrees 0.1 100 2
TRA Alarm activation delay time min 0 200 0
SOU Buzzer enable - no yes no (15)
EAC Alarm message in timing enable - no yes no (16)
min max
unit
Labels of
parameters that
can be modified
Description
Parameter
values
default
notes
LO1 Lower limit of set-point 1 degrees -99 HI1 -99
HI1 Upper limit of set-point 1 degrees LO1 999 999
LO2 Lower limit of set-point 2 degrees -99 HI2 -99 (17)
HI2 Upper limit of set-point 2 degrees LO2 999 999 (17)
SOF Probe calibration offset degrees -50 +50 0.0 (18)
RIS Resolution displayed - HI LO HI (19)
UNI Temperature measurement - C F C (20)
FIL Measurement filter - no yes yes (21)
min max
unit
