Instructions for the installer, maintenance
technician and final user
23
3.5 Stability
The stability of the SandenVendo vending machine is granted whether the vending
machine empty or full and / or with the door open.
The overturning of vending machine without external influences is quite impossible.
Against the vandalism, such as possibility of tilting the Vending machine, the following
optional kits are applicable to meet your needs.
1) Wall fixing kit P/N 135078/2
Components provided:
2 x Welded rear bracket A P/N 130461/1
2 x Bracket B P/N 386460
2 x Plugs with screw P/N 391598
12 x Screw P/N 390139
2) Fixing to the floor
SandenVendo does not assume responsibility for any damage
caused by the lack of consultation of the instructions. All the
operations must be done by authorized personnel.
Fixing to the floor with leveling screw (A)
P/N: 139218 composed by:
4 x Floor mounting bracket P/N:402852
16 x Metal spacer P/N:402854
12 x Screw P/N:V800876
Fixing to the floor with feet (B)
P/N: 139218/1 composed by:
4 x Floor mounting bracket P/N 408028
16 x Metal spacer P/N 407994
Use appropriate material
to secure fixing the
Vending machine to the
floor.
After making 12 holes Ø5mm
tighten the 4 brackets provided
on the cabinet base keeping
an appropriate distance from
each other.
For adjust differences
in level, use the metal
spacers provided.
