Vendo SVE DM6 User Manual

Instructions for the installer, maintenance
technician and final user
31
© SandenVendo Europe SpA
5 USING THE VENDING MACHINE
5.1 Warnings
 CAUTION: DO NOT LOAD THE VENDOR WITH PRODUCTS DIFFERENT FROM
THE ONES RECOMMENDED BY THE MANUFACTURER (refer to chapter PROPER
USE )
5.2 Proper Use
The vending machine G-DRINK DESIGN LINE (DL6-DL9-DV6-DV9-DC6-DM6-DM9) have
been designed and built for vending and distributing the following products:
Model
DL6-DV6
DC6-DM6
Model
DL9-DV9-DM9
Can 0.33
336 (7 Shelf)
504 (7 Shelf)
Bottle capacity 0.50 PET (h.210)
240 (5 Shelf)
360 (5 Shelf)
Bottles 0.50 Coca Cola (h.235)
240 (5 Shelf)
360 (5 Shelf)
Selling cycle time
Max. 13 sec.
No. shelves
from a minimum of 4 to a maximum of 7
Selections
Standard 30 /
Max.42
Standard 45 /
Max.63
PRODUCTS SIZE:
PET bottles, Glass bottles, Cans
Diameter: min. 43,5mm – max. 71,5mm
Height: min. 88mm – max. 266mm
Weight: min. 185g – max. 653g
Carton packs (brick)
Width: min. 52mm – max. 67mm
Depth: min. 40mm – max. 47mm
Height: min. 85mm – max. 134mm
Weight: min. 213g – max. 400g
Attention: Some products although within the above
dimensions could be difficult to load due to their shape.
