Instructions for the installer, maintenance
technician and final user
30
4 ACCESS TO INTERNAL PARTS
Access inside the machine (maintenance area) is possibile yusing the specially provided
key supplied with the vendor (rif. Fig. 4.1).
Access to the service area is possible only using a specially provided tool.
Hereunder is a list of the service areas of the vending machine :
LED (lighting area)
Refrigerant Unit
Transformer box
Fig. 4.1
PRODUCT DELIVERY MECHANISM
