Instructions for the installer, maintenance
technician and final user
35
5.3.1 Loading of bottom left side tray
Follow below procedures for extracting only the first tray on the bottom left side:
1) Manually open the vend door
2) The product bucket moves from left to right allowing extraction of the tray
a. Each opening of the vend door activate the motion from left to right or from
right to left of the bucket
3) Withdraw the tray by lifting slightly before pulling toward you
4) The procedure for product loading is the same as the other trays
When closing the door, the bucket returns to starting position.
