Instructions for the installer, maintenance
technician and final user
36
5.4 How to remove the trays
To remove the trays do the following:
- Place the palm of your hand under the tray and lift it slightly to allow the unhooking from
the shelf.
5.4.1 Replacement of TRAY (SHELF) ASSY height Instruction
When the TRAY ASSY position (height) is changed, please control if the SHELF ASSY is
installed in a collect position.
When the SHELF ASSY is correctly installed, the TRAY ASSY is slightly declined towards
front approx. 3-5 degree (see the machine side view)
To Next Page
