Instructions for the installer, maintenance
technician and final user
47
7.3 Removing and Installing the Bucket
BEFORE STARTING THE VENDING MACHINE DISCONNECT FROM THE
POWER SUPPLY
To re-install, please follow the previous instructions backwards
1. Connect the harness on the left side of the bucket
2. Place the bucket on the moving part and push until it locks into place.
3. Fix with the screws which are removed before.
1. Move the bucket to the middle with
caution.
2. Remove the two screws.
3. Put your finger under the bucket and
unhook the hook and lift it up.
4. Remove the harness on
the left side of the bucket
To Next Page
