3/2002
PC-5
SET-UP AND CODE DESCRIPTION
Error Display Mode
If selection button two is pressed at the “Eror” prompt, the controller will enter the Error
Display Mode. If no errors have occurred, the display will show ”nonE”. If an error has been
detected since the last error reset, the display will show the first error summary code that
has occurred. If selection button three is pressed while displaying any summary code, the
controller will return to the “Eror” prompt.
Eror
Note: See Figure 2 for Error Code Map located on page PC-6.
EXAMPLE: “COLJ” would indicate a column jam error.
Clearing an Error
If selection button two is pressed and held for two seconds during the display of the detailed
error code, that error will be cleared. If any other detailed errors exist, the next error will
now be displayed. If no other errors of this type exist, the next error summary code will now
be displayed, or “nonE” if no other errors exist.
Coin Pay Out/Tube Fill Mode
If selection button one is pressed at the “COIN” prompt, the controller will enter the Coin Pay
Out Mode. The display will show the lowest coin value that can be paid out (.5, .10, .25 etc).
If any of the buttons (e.g.1-3) is pressed, a pay out of the displayed value will be made.
Coins will continue to pay out as long as that selection button is held down.
COIn
EXAMPLE: If selection button one is pressed while 5 cents is displayed it will pay out a
nickel.
Note: If using a four-tube coin changer, selection button four will allow you to pay out the
displayed value.
When the controller enters the coin tube fill mode, the operator is allowed to deposit any
coin into the coin changer’s acceptor when that coin’s tube is not full. The tube inventory
level will be displayed after each coin is accepted.
