1.1 SERVICE PARTS
4
1.0 SERVICE
1.2 PARTS ORDERING CHART
Number
1.
2.
3.
Part Description
Basic Filter
Heat Recovery Core
Damper Motor
Part Number
04432
04433 Canada/ 04455 US
04434
VL0004
2 2
1
1
3
NOTE: Unit in normal position. Can also be installed upside down.
FAE115M,
uFAE115M & vFAE115M
FAE115,
uFAE115 & vFAE115
2.0 T ECHNICAL D ATA
2.1 AIR DISTRIBUTION
VF0014
STALE AIR
FROM HOUSE
FRESH AIR
FROM OUTSIDE
FRESH AIR
TO HOUSE
STALE AIR
TO OUTSIDE
The Figure 1 illustrates the air flow inside units (all models).
Figure 1
