• Never leave the charger unsupervised when it is connected to its power supply. If any
malfunction is observed immediately terminate the process and refer to the operation manual.
• Keep the charger away from dust, dampness or rain, heat, or direct sunshine and vibration.
• The circuit of the unit is designed to be powered by a 10-18V DC only.
• This unit and the battery to be charged or discharged should only be set upon a heat resistant,
non-ammable and non-conductive surface. Never charge on a car seat, carpet or similar
surface. Keep all ammable or volatile materials well away from operating area.
• Be sure to understand the specications of the battery to be charged or discharged. If the
program is set up incorrectly the battery can severely be damaged. Lithium batteries when
improperly charged, can cause permanant damage or re.
• To avoid short-circuits between the charge lead, always connect the charge cable to the unit
first and only then to the battery to be charged or discharged. Reverse the sequence when
disconnecting.
• Do not attempt to disassemble battery packs.
NiCd/NiMH
Lilo
LiFe
LiPo
PB
voltage level:1.2V/cell
allowable fast charge current:1C~2C depends on the
performance of cell discharge voltage cut off level
0.85V/cell(NiCd), 1.0V/cell(NiMH)
voltage level:3.6V/cell
max.charge voltage:4.1V/cell
allowable fast charge current: 1C or less
min.discharge voltage cut off level:2.5V/cell or higher
voltage level:3.3V/cell
max.charge voltage:3.6V/cell
allowable fast charge current: 4C or less(e.g. A123M1)
discharge voltage cut off level:2.0V/cell or higher
voltage level:2.0V/cell
voltage level:3.7V/cell
max.charge voltage:4.2V/cell
allowable fast charge current: 1C or less
discharge voltage cut off level:3.0V/cell or higher
(Lead-acid) max.charge voltage:2.46V/cell
allowable fast charge current:0.4C or less
discharge voltage cut off level:1.50V/cell or higher
