Model AH510 / AH515 AH530 / AH535 AH550 / AH555
For room sizes* 35m² 45m² 60m²
Interactive touch display Standard
App control Standard WiFi
Colours brillant white / brillant black
Power levels 3 + Automatic
Noise emission
(speeds 1–3)
24/34/44 dB(A) 24/34/44 dB(A) 24/35/45 dB(A)
Power consumption
(speeds 1–3)
3/5/8 watts
Mains voltage 100240 V, 50 / 60 Hz
Water capacity (max.) 5 litres 7 litres 10 litres
Dimensions (L x W x H) 26×28×31 cm 30×30×33 cm 45×30×33 cm
Weight approx. 3kg approx. 3.5kg approx. 5.2kg
WLAN frequency range 2.4 GHz
WLAN transmission
power
Maximum 20 dBm
* based on a ceiling height of max. 2.5 metres
May be subject to modifications and errors
TECHNICAL DATA
