IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your unit, please provide the model number and the serial number. We reserve the right to
change parts due to technology upgrades or availability. Contact an authorized dealer to obtain
any of these parts. Never use substitute materials. Use of non-approved parts can result in poor
performance and safety hazards.
# Item Description Qty
1 SE72023 AIR CONTROL HOUSING ASSEMBLY 1
2 PL72053 AIR INTAKE CLOSING PLATE 1
3 30154 BLACK SCREW #10 X 5/8" QUADREX #2 TYPE A 2
4 AC05959 METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL 1
5 AC01275 FIRE SCREEN DOOR 1
6 30556 AIR CONTROL FINISHING TIP 1
7 30029 THREAD CUTTING SCREW 10-24 TYPE "F" X 3/8" HEX WASHER 2
8 PL72274 PRIMARY AIR CONTROLE SLIDER PLATE 1
9 30187 STAINLESS WASHER ID 17/64" X OD 1/2" 2
10 30206 ZINC WASHER 5/16"ID X 3/4"OD 1
11 30060
THREAD-CUTTING SCREW 1/4-20 X 1/2" F HEX STEEL SLOT WASHER C102 ZINC
1
12 44122 DOUBLE CAGE BLOWER 176 CFM (CLASS H) 1
13 44125 FORCED AIR DISTRIBUTION KIT PC CARD 1
14 AC01374 FORCED AIR DISTRIBUTION KIT 300 CFM 1
15 SE46162 HE250R INSTRUCTION MANUAL KIT 1
16 SE24336 VENTIS CAST IRON DOOR 1
17 SE72135 REPLACEMENT HANDLE WITH LATCH KIT 1
18 30131 BLACK METAL SCREW #10 X 1/2" TYPE "A" PAN QUADREX 1
19 44203 RHEOSTAT WASHER 1
20 44202 RHEOSTAT NUT 1
21 44091 ROCKER SWITCH 2 POSITION MSR-8 1
22 PL72164 BLOWER CONTROL PANEL 1
23 44084 RHEOSTAT WITHOUT NUT AND FLAT WASHER 1
24 44028 CERAMIC THERMODISC F110-20F 1
25 30025 1/4-20 X 1/2" PAN-HEAD QUADREX BLACK SCREW 1
26 30898 ROUND WOODEN BLACK HANDLE DULL BLACK FINISH 1
27 30117 SOCKET SET SCREW #10-32 X 1/4" 2
28 30586 HINGE PIN 2
29 60204A TERMINAL 3/8" SECTION 2
30 60204B TERMINAL BLOCK (END SECTION) 1
31 30101 SPRING TENSION PIN 5/32"Ø X 1 1/2"L 1
32 AC06400 3/4" (FLAT) X 6' BLACK SELF-ADHESIVE GLASS GASKET 1
33 SE72341 VENTIS GLASS 1
34 PL72314 GLASS FRAME 2
35 SE53585 GLASS RETAINER KIT WITH SCREWS (12 PER KIT) 1
36 AC06500 SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT 1
37 PL72161 CONVECTION JACKET SPACER 4
