PARTS
Illustrated Parts - 33
Use only original Ventrac
replacement parts.
REF. PART NO. DESCRIPTION QTY.
1 .........29.GF0001 .................Grease Ftg, 1/4 SAE ST ..................................................... 1
2 .........99.B0057-2 .................Washer, Mach 3/4 x 1-1/4 10 GA ZP ........................................... 3
3 .........95.08 ......................Washer, Flat 1/2 SAE ....................................................... 7
4 .........90.0834 ....................Bolt, 1/2-13 USS x 4-1/4 ..................................................... 1
5 .........90.0848 ....................Bolt, 1/2-13 USS x 6 ........................................................ 2
6 .........99.A08 .....................Locknut, Stover 1/2-13 USS .................................................. 5
7 .........99.B0089 ...................Washer, Mach 3/4 x 1-1/4 14 GA .............................................. 3
8 .........47.0476 ....................Grip, Handle Black Vinyl ..................................................... 1
9 .........95.10 ......................Washer, Flat 5/8 SAE ....................................................... 2
10 ........90.1048 ....................Bolt, 5/8-11 USS x 6 ........................................................ 1
11 .........99.A10 .....................Locknut, Stover 5/8-11 USS .................................................. 1
12 ........MK-1150 ...................Bushing, Pivot Clamp ....................................................... 2
13 ........85.B0077 ...................Bushing, 3/4 ID X 1 OD X 1 .................................................. 6
14 ........MK-1146 ...................Bushing, Rocker Pivot ...................................................... 1
15 ........00.0577 ....................Decal, Cut Height Position Key ............................................... 1
16 ........MK-1152 ...................Plate, Height Adjust ........................................................ 1
17 ........97.0508 ....................Bolt, Carriage 5/16-18 x 1 .................................................... 2
18 ........99.E0102 ...................Nut, Locking Flange 5/16-18 ................................................. 2
19 ........03.0002 ....................Pin, Ball 3/8 x 2” W/ Ring Grip ................................................ 1
20 ........00.0575 ....................Decal, Height Adjust Left .................................................... 1
21 ........42.0601 ....................Rod, Thread 1/2-20 x 20.0 RH/LH ZP .......................................... 1
22 ........97.0814 ....................Bolt, Carriage 1/2-13 x 1-3/4 ................................................. 2
23 ........99.E0079 ...................Nut, Jam 1/2-20 RH ZP ..................................................... 1
24 ........99.E0080 ...................Nut, Jam 1/2-20 LH ZP ...................................................... 1
25 ........MK-6026 ...................Rocker, Left Front .......................................................... 1
26 ........MK-6031 ...................Rocker, Left Rear .......................................................... 1
27 ........MK-6003 ...................Frame, Carrier Left ......................................................... 1
28 ........43.008 .....................Rod End, 1/2 Spherical ...................................................... 1
29 ........43.008L ....................Rod End, 1/2 Spherical LH Thrd ............................................... 1
Left Carrier Rockers & Link
To Next Page
