PARTS
Illustrated Parts - 43
Use only original Ventrac
replacement parts.
REF. PART NO. DESCRIPTION QTY.
1 .........95.06 ......................Washer, Flat 3/8 SAE ....................................................... 6
2 .........83.0075 ....................Pulley, 5.64 OD, 25MM Str. Bore .............................................. 1
3 .........83.2BK5725 ................Pulley, 5.7” 2 Groove, 25mm Bore, 1/4” Keyway .................................. 2
4 .........99.B0057-2 .................Washer, Mach 3/4 x 1-1/4 10 GA ZP ........................................... 3
5 .........99.A12NF ..................Locknut, Stover 3/4-16 SAE .................................................. 3
6 .........83.0031 ....................Pulley, V-Idler 5-1/4 X 3/8 ID ................................................. 3
7 .........90.0614 ....................Bolt, 3/8-16 USS x 1-3/4 ..................................................... 3
8 .........99.SF06 ....................Nut, SRF 3/8-16 USS ....................................................... 4
9 .........99.A06 .....................Locknut, Stover 3/8-16 USS .................................................. 1
10 ........90.0414 ....................Bolt, 1/4-20 USS x 1-3/4 ..................................................... 1
11 .........99.SF04 ....................Nut, SRF 1/4-20 USS ....................................................... 4
12 ........90.0408 ....................Bolt, 1/4-20 USS x 1 ........................................................ 1
13 ........83.BK45H ..................Pulley, 4.5” H-Bushing ...................................................... 1
14 ........40.0399 ....................Idler Arm, Belt Tension ...................................................... 1
15 ........64.0602 ....................Bushing, 3/8 x 5/8 x .265 .................................................... 1
16 ........94.06 ......................Washer, Flat 3/8 USS ....................................................... 1
17 ........99.SF0608 ..................Bolt, SRF 3/8-16 USS x 1 .................................................... 1
18 ........85.B0088 ...................Bushing, 5/8 ID X 3/4 OD X 1/2 ............................................... 2
19 ........64.1936 ....................Bushing, Belt Tension Pivot .................................................. 1
20 ........90.0618 ....................Bolt, 3/8-16 USS x 2-1/4 .................................................... 1
21 ........03.0022 ....................Pin, Ball 1/4” x 1” .......................................................... 1
22 ........41.0048 ....................Spring, Ext. 1 Od X 6 ....................................................... 1
23 ........81.0180 ....................Belt, B190 Custom ......................................................... 1
24 ........60.1056 ....................Cover, Pulley ............................................................. 4
25 ........MK-6019 ...................Handle, Belt Tensioner ...................................................... 1
26 ........81.0160 ....................Chain, 1/8 Plated x 4 Links ................................................... 1
Main Deck Belt, Pulleys, & Belt Tensioner
