VERDER VA 50 - Page 22

22 819.4496
Service
Cutaway View, with Diaphragms in Place Cutaway View, with Diaphragms Removed
FIG. 13_______________________________________________________________________
04708
03982
24 104 401*
403*
105
19 402*
1
1
1
2 4
23
5
24
104
403*
401*
24
1
105
3
3
2
2 4
5
04621B
Lips face out of housing (1).
Air Side must face center housing (1).
Grease.
Used on Models with two–piece PTFE diaphragms
only.
Apply medium-strength (blue) Loctite® or equivalent.
Torque to 27 to 34 N•m at 100 rpm maximum.
1
2
3
4
5
