Top View
Note:
y The figures are only for your reference, the actual shape and color of the product may differ
slightly.
7
8
9
10
1
2
3
4
5
6
1 Power on/off switch 6 Antenna port
2 Telephone port 1 7 Signal strength indicators
3 Telephone port 2 8 Battery indicator
4 USB port* 9 Power indicator
5 DC 12V power port 10 Voice mail indicator
* Note: Never place a USB-based device into the USB port of the Home Phone Connect under any
circumstances. Doing so may damage the device and negate its warranty. The port was designed for
diagnostic purposes only; it is not intended for customer use.
