Versamatic E2 - Page 3

Table of Contents
SECTION 1: PUMP SPECIFICATIONS ..............1
• Nomenclature
• Materials
• Performance
• Dimensional Drawings
SECTION 2: INSTALLATION & OPERATION ...8
• Principle of Pump Operation
• Typical Installation Guide
• Troubleshooting
SECTION 3: EXPLODED VIEW ........................ 11
• Composite Drawings
• Parts List
• Material Codes
SECTION 4: AIR END ......................................14
• Air Distribution Valve Assembly
• Pilot Valve Assembly
• Intermediate Assembly
SECTION 5: WET END.....................................18
• Diaphragm Drawings
• Diaphragm Servicing
SECTION 6: WARRANTY & CERTIFICATES ..20
• Warranty
• EU Declaration of Conformity - Machinery Directive
• EU Declaration of Conformity - ATEX Directive
*More than one option may be specied for a particular pump model.
Model
Pump Size
Wetted Parts
Non-Wetted Parts
Diaphragm Material
Diaphragm Series
Valve Ball Material
Seat
Construction Design
Design Level
Options (if applicable)
Your Serial #: (ll in from pump nameplate) _____________________________________
Model #:
__ __ __ __ __ __ __ __ __ __ __ __ __
(ll in from pump
nameplate)
Your Model #:
Model Pump Size Wetted Parts Non-Wetted Parts Diaphragm Material
E Elima-Matic 2 2” P Polypropylene P Polypropylene 1 Neoprene
2 Nitrile
3 FKM (Fluorocarbon)
4 EPDM
6 Santoprene XL
7 Hytrel
Diaphragm Series Valve Flap Material Valve Seat Construction Design Miscellaneous Options
R Rugged 1 Neoprene S Stainless Steel 9 Bolted B BSP Tapered Thread
X Thermo-Matic 2 Nitrile F Flap Valve Pump
4 EPDM N NPT Tapered Thread
7 Hytrel
Design Level
A
Explanation of Pump Nomenclature
Model E2 Bolted Plastic Flap • 32
• Model E2 Bolted Plastic Flap
1: PUMP SPECS 1: PUMP SPECS2: INSTAL & OP3: EXP VIEW4: AIR END
