Versamatic E2 - Dimensional Drawings

Dimensional Drawings
E2 Plastic Bolted Flap - Flanged Manifold
Dimensions in inches (metric dimensions in brackets)
The dimensions on this drawing are for reference only. A certied drawing can be requested if physical dimensions are needed.
SAFE AIR
EXHAUST
DISPOSAL
AREA
PUMP INSTALLATION AREA
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
MUFFLER
LIQUID
LEVEL
SUCTION
LINE
LIQUID
LEVEL
SUCTION
LINE
MUFFLER
MUFFLER
SUBMERGED ILLUSTRATION
IMPORTANT
When the pumped product source is at a higher
level than the pump (ooded suction condition),
pipe the exhaust higher than the product source
to prevent siphoning spills. In the event of a
diaphragm failure a complete rebuild of the
center section is recommended.
22.36
568
4X .57
15
3.50
89
29.20
742
.78 X .87 SLOTTED
UNIVERSAL FLANGE FITS ANSI 125# CONNECTION
OR PN10 50MM DIN CONNECTION
A
B
2X 3.77
96
11.25
286
19.03
483
.78 X .87 SLOTTED
UNIVERSAL FLANGE FITS ANSI 125# CONNECTION
OR PN10 50MM DIN CONNECTION
.60
15
8.90
226
12.03
306
4.94
125
14.15
360
10.75
273
AIR INLET
3/4 NPT
MUFFLER 1" NPT EXHAUST PORT FOR
OPTIONAL MUFFLER STYLES OR PIPING
EXAUST AIR IN SUBMERGED APPLICATIONS
E2PPxxxx9A-F
DIMENSIONAL TOLERANCE .13 [3]
MUFFLER OPTION DIM "A" DIM "B"
INTEGRAL MUFFLER 6.88 [175] 12.65 [321]
E2 Plastic Bolted Flap Non-Metallic
Dimensions in Inches [ ] in Millimeters. Dimensional tolerance: +/- 1/8" [ ] +/- 3mm
Dimensional Drawings
SAFE AIR
EXHAUST
DISPOSAL
AREA
PUMP INSTALLATION AREA
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
1" DIAMETER AIR
EXHAUST PIPING
MUFFLER
LIQUID
LEVEL
SUCTION
LINE
LIQUID
LEVEL
SUCTION
LINE
MUFFLER
MUFFLER
SUBMERGED ILLUSTRATION
IMPORTANT
When the pumped product source is at a higher
level than the pump (ooded suction condition),
pipe the exhaust higher than the product source
to prevent siphoning spills. In the event of a
diaphragm failure a complete rebuild of the
center section is recommended.
29.70
754
20.89
531
2X .13
3
2.00
51
9.78
248
17.56
446
3.00
76
3.00
76
SUCTION
PORT
2" NPT
2" BSPT
DISCHARGE PORT
2" FNPT
2" BSPT
12.02
305
4X
.41
10
9.00
229
AIR INLET
3/4 NPT
STANDARD ENCAPSULATED
MUFFLER 1" NPT EXHAUST PORT FOR
OPTIONAL MUFFLER STYLES OR PIPING
EXAUST AIR IN SUBMERGED APPLICATIONS
DIMENSIONAL TOLERANCE .13 [3]
MUFFLER OPTION DIM "A" DIM "B"
INTEGRAL MUFFLER 6.88 [175] 12.65 [321]
Dim A
Dim B
E2PPxxxx9A-B or -N
Model Specic
Model E2 Bolted Plastic Flap • 65
• Model E2 Bolted Plastic Flap
1: PUMP SPECS 1: PUMP SPECS
