VERSARE MP10 - Connecting the Panels; End Panels; Attach End Panel Plates

With panels laid out next to each other, all Velcro tabs facing up, use 1 Hinge Plate and 2
Screws for each connection point of the completed panels.
+
+
5.
When all the panels are connected, top and bottom, for a total of 4 secured hinge plates
(5-panel) or 8 secured hinge plates (7-panel), fold up screen like an accordion and set aside.
Assemble the end panels with the reserved materials in Step 1. Layout each of the two
remaining canvas panels, Velcro closures facing up. Insert 2 part D, connecting them with
the 4 part B remaining. Secure frame with 4 Screws.
D
D
B
B
End Panel
End Panel
6.
End Panels
Connecting the Panels
With both end panels fl at on the ground,
Velcro closures facing up, locate two
screw holes in each of the End Panel
Frame Caps below the canvas. Use 2
Screws per end panel frame cap to
secure each of the 4 End Panel Plates,
pointed end facing up.
7.
Attach End Panel Plates
3
