Vertex Standard EVX-531 Service Manual

EVX-531 UHF Service Manual 7
Parts List
When replace a chip fuse,
use the part of the same type and value.
REF. DESCRIPTION VALUE MFR’s DESIG VXSTD P/N
MAIN-2 UNIT CB6338000: TYPE “G6”
F 2001 CHIP FUSE 3.15A, 36V FHC16 322ADTP Q0000118
MC2001 MIC. ELEMENT PF0-1055P M3290045
Q 2513 FET RQA0011DNS G3070392
S 2001 TACT SWITCH EVQPUB02K N5090167
S 2002 TACT SWITCH EVQP8403M N5090173
S 2003 TACT SWITCH EVQPUB02K N5090167
S 2004 TACT SWITCH EVQPUB02K N5090167
S 2006 ROTARY SWITCH TP7NBPC16 14.7F RY-10115 N0190198
TH2001 THERMISTOR TH05 4B473FR G9090150
VR2001 POT. TP76N975N13.5FB503RY10034 J60800314
X 2001 XTAL 32.768kHz 4809995L18 32.768KHZ H0103407
X 2501 TCXO 19.2MHz TTS27NSC-A7 19.2MHZ H9501380
XF2501 XTAL FILTER DSF753SDF 50.85MHZ H1102479
SHIELD COVER (FET) RA1483000
SHEET (HEAT8X8t1) RA1483100
NUT 2 psc (C065) RA090590A
PAN HEAD TAPTITE-B 9 pcs M2X5 U44105001
MAIN-3 UNIT CB6611000: TYPE “G6”
CB6609000: TYPE “G7”
F 3001 CHIP FUSE 3.15A, 36V FHC16 322ADTP Q0000118
F 3301 CHIP FUSE 1.15A, 36V FCC16 132ABTP Q0000109
MC3001 MIC. ELEMENT PF0-1055P M3290045
Q 3513 FET RQA0011DNS G3070392
S 3001 TACT SWITCH EVQPUB02K N5090167
S 3002 TACT SWITCH EVQP8403M N5090173
S 3003 TACT SWITCH EVQPUB02K N5090167
S 3004 TACT SWITCH EVQPUB02K N5090167
S 3006 ROTARY SWITCH TP7NBPC16 14.7F RY-10115 N0190198
TH3001 THERMISTOR TH05 4B473FR G9090150
VR3001 POT. TP76N975N13.5FB503RY10034 J60800314
X 3001 XTAL 32.768kHz 4809995L18 32.768KHZ H0103407
X 3501 TCXO 19.2MHz TTS27NSC-A7 19.2MHZ H9501380
XF3501 XTAL FILTER DSF753SDF 50.85MHZ H1102479
SHIELD COVER (FET) RA1483000
SHEET (HEAT8X8t1) RA1483100
NUT 2 psc (C065) RA090590A
PAN HEAD TAPTITE-B 9 pcs M2X5 U44105001
