EVX-531 UHF Service Manual 6
REF. DESCRIPTION VALUE MFR’s DESIG VXSTD P/N
Parts List
FRONT CASE ASSY CB6341000
FRONT CASE SUB ASSY CB6388000
KNOB (VOL) RA125100A
KNOB (CH) RA125110A
WASHER RA1396900
BUSH 2 pcs RA125090A
RUBBER PACKING (SP) RA066320A
SP HOLDER 2 pcs RA1458300
SPEAKER 4-ohm 36N-D2114B M4090157
WIRE ASSY T9207535A
MIC/SP CAP ASSY CB6343000
BIND HEAD TAPTITE-B 2 pcs M2X5 U24105001
CHASSIS ASSY
(
w/o Option Connector
)
CB6613000
RUBBER PACKING (CHASSIS) RA1448500
RUBBER BOOTS RA1458000
SHEET (6x6) RA037690B
PAD TYPE “G6” (EMI-ABSORBER) RA1364100
BIND HEAD TAPTITE-B 2 pcs 2X10 U24110001
CHASSIS ASSY
(
w/ Option Connector
)
CB6614000
RUBBER PACKING (CHASSIS) RA1448500
RUBBER BOOTS RA1458000
SHEET (6x6) RA037690B
PAD TYPE “G6” (EMI-ABSORBER) RA1364100
PAN HEAD SCREW 2 pcs M2X2.5 (3KA) U07225001
BIND HEAD TAPTITE-B 2 pcs 2X10 U24110001
MAIN UNIT CB6389000: TYPE “G7”
F 1001 CHIP FUSE 3.15A, 36V FHC16 322ADTP Q0000118
MC1001 MIC. ELEMENT PF0-1055P M3290045
Q 1513 FET RQA0011DNS G3070392
S 1001 TACT SWITCH EVQPUB02K N5090167
S 1002 TACT SWITCH EVQP8403M N5090173
S 1003 TACT SWITCH EVQPUB02K N5090167
S 1004 TACT SWITCH EVQPUB02K N5090167
S 1006 ROTARY SWITCH TP7NBPC16 14.7F RY-10115 N0190198
TH1001 THERMISTOR TH05 4B473FR G9090150
TH1501 THERMISTOR TH05 4B473FR G9090150
VR1001 POT. TP76N975N13.5FB503RY10034 J60800314
X 1001 XTAL 32.768kHz 4809995L18 32.768KHZ H0103407
X 1501 TCXO 19.2MHz TTS27NSC-A7 19.2MHZ H9501380
XF1501 XTAL FILTER DSF753SDF 50.85MHZ H1102479
SHIELD COVER (FET) RA1483000
SHEET (HEAT8X8t1) RA1483100
NUT 2 psc (C065) RA090590A
PAN HEAD TAPTITE-B 9 pcs M2X5 U44105001
When replace a chip fuse,
use the part of the same type and value.
