EVX-S24 UHF Digital/Analog Transceiver Service Manual 5
REF. DESCRIPTION VALUE MFR’s DESIG VXSTD P/N
When replace a chip fuse,
use the part of the same type and value.
FRONT CASE ASSY
(
BLK
)
CB7117000
FRONT CASE ASSY
(
YEL
)
CB7118000
O RING
(
PANEL
)
RA1631000
REAR CASE ASSY
(
BLK
)
CB7119000
REAR CASE ASSY
(
YEL
)
CB7120000
LIGHT GUIDE
(
TX/RX
)
RA1632300
SHEET
(
MICROTEX C012
)
RA0337300
SHEET
(
VENT
)
RA1639600
O RING
(
SCREW
)
RA1639400
Y-RECESS TAPTITE-B
(
x2 pcs
)
2X22SUS B U9900309
Y-RECESS TAPTITE-B
(
x2 pcs
)
2X13NI U9900311
Y-RECESS SCREW
(
x2 pcs
)
M2X16.5NI U9900313
BATTERY COVER ASSY
(
BLK
)
CB7122000
BATTERY COVER ASSY
(
YEL
)
CB7123000
O RING
(
BATTERY
)
RA1633400
CHASSIS ASSY CB7121000
TERMINAL CONDUCTIVE PAD
(
CHG
)
RA1640600
SHEET
(
x2 pcs
)
(
6X6
)
RA037690B
O RING
(
4.9X1.9
)
RA1037400
SHIELD SHEET RA1643200
MECHANICAL PARTS
KNOB
(
VOL
)
RA1634600
LID
(
USB
)
RA1643200
RUBBER CAP
(
JACK
)
RA1634500
BUSH RA125090A
ELECTRICAL PARTS
WIRE ASSY FR027890B
MAIN UNIT ASSY CB7124000
F 1001 CHIP FUSE
3.15A, 36V FHC16 322ADTP Q0000118
F 1002 CHIP FUSE
2A, 36V FCC16 202ADTP Q0000147
F 1003 CHIP FUSE
2A, 36V FCC16 202ADTP Q0000147
J 1003 CONNECTOR ZX62D-B-5PA8
(
30
)
P1091565
J 1005 CONNECTOR 03-A70G0-36BKA P1091581
Q 1016 FET RD04LUS2-T212 G3070525
S 1001 TACT SWITCH EVQP42B3M N5090176
S 1002 TACT SWITCH EVQP42B3M N5090176
TH1001 THERMISTOR TH05 4B473FR G9090150
VR1001 POT. TP76N975N13.5FB503RY10034 J60800314
X 1001 TCXO 19.2MHz NT2520SB 19.2MHZ H9501523
GASKET
(
JACK
)
RA1632900
RING NUT RA157250A
PAN HEAD SCREW M2X3NI #3 U07230302
PAN HEAD TAPTITE-B (x4 pcs) 2X5 #2 U9900307
DISPLAY UNIT ASSY
(
BLK
)
CB7125000
DISPLAY UNIT ASSY
(
YEL
)
CB7129000
DS2001 LCD GTA4716SY01 G6090231
MC2001
MICROPHONE ELEMENT
PFO-T6022P-1.5 M3290060
S 2001 TACT SWITCH SKRMABE010 N5090172
S 2002 TACT SWITCH SKRMABE010 N5090172
S 2003 TACT SWITCH SKRMABE010 N5090172
GROUBD PLATE
(
133
)
RA1642300
PAN HEAD TAPTITE-B
(
x3 pcs
)
2X5 #2 U9900307
Parts List
