Vertex Standard VX-2200 Series Service Manual

h-16
MAIN-2 Unit (50 W: Lot. 33 ~)
VX-2100/-2200
(
VHF
)
Service Manual
R 5301 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 33- B c5
R 5302 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 33- B b5
R 5303 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 33- A I5
R 5304 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 33- B c5
R 5306 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 33- B c5
R 5307 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 33- B b5
R 5308 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 33- B c5
R 5309 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 33- B b5
R 5310 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 33- A I4
R 5311 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 33- B c5
R 5312 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 33- B b5
R 5313 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 33- B c5
R 5314 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 33- B c5
R 5315 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 VTX(USA) 33-79 B g5
R 5315 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 80- B g5
R 5316 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 33- B c4
R 5317 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 33- B i1
R 5318 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 33- A B2
R 5319 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 33- A A1
R 5320 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 33- A C4
R 5321 CHIP RES. 20k 1/16W 0.5% RR0510R-203-D J24189150 33- A C4
R 5322 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 33- A C4
R 5323 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 33- A C4
R 5324 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 33- A C3
R 5325 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 33- A C4
R 5326 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 33- A C4
R 5327 CHIP RES. 20k 1/16W 0.5% RR0510R-203-D J24189150 33- A C4
R 5328 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 33- A C4
R 5329 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 33- A C4
R 5330 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 33- A B2
R 5331 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 33- A G5
R 5333 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 VTX(USA) 33-79 B f5
R 5333 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 80- B f5
R 5334 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 33- A A5
R 5335 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 33- B j1
R 5338 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 33- A I5
R 5339 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 33- A F4
R 5340 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 33- A E3
R 5347 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 33- A E4
R 5348 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 33- A H5
R 5349 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 33- A H5
R 5352 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 33- B i1
R 5353 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 33- B j1
SC5001 SHIELD CASE (VCO) RA079040A 33-
TH5001 THERMISTOR ERTJ0EV473J G9090120 33- B e2
TH5002 THERMISTOR ERTJ0EV473J G9090120 33- B c5
VR5001 POT. RK0971111 20KA/SW J60800256 33- A A5
X 5001 XTAL HC-49SMD 11.0592MHz FYSMD110592 H0103318 33- A A4
X 5002 TCXO 16.8MHz TTS14VSB-A3 16.80MHZ H9501100 33- A G4
X 5003 XTAL U3B 4.194304MHz 4.194304MHZ H0103284 VTX(USA) 33-79 B g5
X 5003 XTAL U3B 4.194304MHz 4.194304MHZ H0103284 80- B g5
XF5001 XTAL FILTER TF4-67EA1 67.65MHZ H1102399 33-84 A H4
XF5001 XTAL FILTER MFT67P 67.650MHZ H1102471 85- A H4
LEAF SPRING RA0824400 33-
Parts List
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
