Vertex Standard VX-2200 Series Service Manual

I-3
Parts List
FRONT-A Unit (VX-2100)
VX-2100/-2200
(
VHF
)
Service Manual
PCB with Components CB3472001
C 2001 CHIP TA.CAP. 4.7uF 25V TEESVB21E475M8R K78140019 1- B e2
C 2002 CHIP CAP. 0.1uF 25V B GRM21BB11E104KA01L K22140811 1- B e2
C 2003 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e2
C 2004 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025 1- B e2
C 2005 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e2
D 2001 LED BRPG1211C-TR G2070654 1- A B1
D 2002 LED TLGU1008A(T04) G2070956 1- A B1
D 2003 LED TLGU1008A(T04) G2070956 1- A C1
DS2001 LED ELS-512SURWA/S530-A3 G2090796 1- A D1
J 2001 CONNECTOR 18FLT-SM2-TB(LF)(SN)(M) P1091176 1- B e1
Q 2001 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b1
Q 2001 TRANSISTOR DTC144EE TL G3070075 23- B b1
Q 2002 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B c1
Q 2002 TRANSISTOR DTC144EE TL G3070075 23- B c1
Q 2003 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B c2
Q 2003 TRANSISTOR DTC144EE TL G3070075 23- B c2
Q 2004 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b2
Q 2004 TRANSISTOR DTC144EE TL G3070075 23- B b2
Q 2005 IC CD4094BPWR G1093866 1- B b1
Q 2006 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b2
Q 2006 TRANSISTOR DTC144EE TL G3070075 23- B b2
Q 2007 IC UA78L05ACPK G1094156 1-69 B e2
Q 2007 IC UA78L05ACPKE6(TAPE) G1094229 70- B e2
Q 2008 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b2
Q 2008 TRANSISTOR DTC144EE TL G3070075 23- B b2
Q 2009 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b1
Q 2009 TRANSISTOR DTC144EE TL G3070075 23- B b1
Q 2010 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 B b1
Q 2010 TRANSISTOR DTC144EE TL G3070075 23- B b1
Q 2011 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 A B2
Q 2011 TRANSISTOR DTC144EE TL G3070075 23- A B2
Q 2012 IC CD4094BPWR G1093866 1- B d2
Q 2013 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 A B2
Q 2013 TRANSISTOR DTC144EE TL G3070075 23- A B2
Q 2014 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 A C1
Q 2014 TRANSISTOR DTC144EE TL G3070075 23- A C1
Q 2015 TRANSISTOR RT1N441U-T11-1 G3070247 1-22 A C2
Q 2015 TRANSISTOR DTC144EE TL G3070075 23- A C2
R 2001 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c1
R 2001 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c1
R 2002 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c1
R 2002 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c1
R 2003 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c2
R 2003 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c2
R 2004 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c2
R 2004 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c2
R 2006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B f1
R 2007 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c2
R 2007 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c2
R 2008 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B b2
R 2008 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B b2
R 2009 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B b1
R 2009 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B b1
R 2010 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1-21 B c1
R 2010 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 22- B c1
R 2011 CHIP RES. 820 1/16W 5% RMC1/16S 821JTH J24189024 1- A B2
R 2012 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 1- A B2
R 2013 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A C1
R 2014 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A C2
Z 2001 HOLDER (LG) RA0787500 1-4
Z 2001 HOLDER (LG) RA078750A 5-
Z 2002 LIGHT GUIDE (8ch) RA0787600 1-
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
