Vertex Standard VXR-7000 Service Manual

121VXR-7000 UHF Service Manual
PCB with Components CS1687003 VERSION D (Except EIA/CE)
CS1687004 VERSION D (EIA/CE)
CS1687005 VERSION A (Except EIA/CE)
CS1687006 VERSION A (EIA/CE)
CS1687007 VERSION BS1 (Except EIA/CE)
CS1687008 VERSION BS1 (EIA/CE)
C 5501 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b2
C 5502 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c2
C 5503 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 EIA/CE 19-61
C 5503 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 VERS. A (EIA/CE) 62-107
C 5503 AL.ELECTRO.CAP. 10uF 25V EEEHA1E100R K48140009 VERS. A (EIA/CE) 108-
C 5503 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 VERS. BS1 (ex. EIA/CE) 62-107
C 5503 AL.ELECTRO.CAP. 10uF 25V EEEHA1E100R K48140009 VERS. BS1 (ex. EIA/CE) 108-
C 5503 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 VERS. BS1 (EIA/CE) 62-107
C 5503 AL.ELECTRO.CAP. 10uF 25V EEEHA1E100R K48140009 VERS. BS1 (EIA/CE) 108-
C 5503 AL.ELECTRO.CAP. 10uF 25V RC2-25V100ME1# K40149012 VERS. D (EIA/CE) 62-107
C 5503 AL.ELECTRO.CAP. 10uF 25V EEEHA1E100R K48140009 VERS. D (EIA/CE) 108-
D 5501 LED TLG208 G2090147 1-57 A C3
D 5501 LED L-4F3GD G2090789 58- A C3
D 5502 DIODE 1SS355 TE-17 G2070470 1- B d3
D 5503 DIODE 1SS355 TE-17 G2070470 1- B b3
D 5504 DIODE 1SS355 TE-17 G2070470 1- B a3
D 5505 LED TLG208 G2090147 1-57 A E3
D 5505 LED L-4F3GD G2090789 58- A E3
D 5506 DIODE 1SS355 TE-17 G2070470 1- B c3
D 5507 LED TLG208 G2090147 1-57 A F3
D 5507 LED L-4F3GD G2090789 58- A F3
D 5508 LED TLG208 G2090147 1-57 A D3
D 5508 LED L-4F3GD G2090789 58- A D3
D 5509 LED GL3KG8 G2090432 1-162 A A1
D 5509 LED EMBG3368S G2090828 163- A A1
D 5510 LED GL3HY8 G2090434 1-162 A A2
D 5510 LED EMBG3368S G2090828 163- A A2
J 5501 CONNECTOR SB20-06WS P0090613 1- B a2
J 5502 CONNECTOR 12FMZ-BT(LF)(SN) P1090901 1- B a2
J 5503 CONNECTOR R41-2509H P1090714 1- A A3
JP5501 WIRE ASSY A1367+ T9206796A 1- B a2
Q 5501 TRANSISTOR DTC323TK T146 G3070042 1- B a2
Q 5502 TRANSISTOR XN1213-(TX) G3070194 1-167 B d3
Q 5502 TRANSISTOR DMC261030L G3070445 168- B d3
Q 5503 IC BU4094BCFV-E1 G1092128 1-22 B d2
Q 5503 IC BU4094BCFV-E2 G1093527 23- B d2
Q 5504 TRANSISTOR XN1213-(TX) G3070194 1-167 B b3
Q 5504 TRANSISTOR DMC261030L G3070445 168- B b3
Q 5505 TRANSISTOR XN1213-(TX) G3070194 1-167 B f1
Q 5505 TRANSISTOR DMC261030L G3070445 168- B f1
Q 5506 TRANSISTOR DTC144EK T146 G3070033 1- B f1
R 5501 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B a2
R 5502 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- B a2
R 5505 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B d3
R 5506 CHIP RES. 10k 1/10W 5% RMC1/10T 103J J24205103 1- B c2
R 5507 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B b3
R 5508 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B a3
R 5509 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B c3
R 5510 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B f1
R 5511 CHIP RES. 470 1/4W 5% RMC1/4 471JATP J24245471 1- B f1
R 5512 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B f1
S 5501 TACT SWITCH EVQ-333 H=5.0(TAPE) N5090046 1- A C1
S 5502 PUSH SWITCH SPPH110300 N4090142 1- A C3
S 5503 PUSH SWITCH SPPH110300 N4090142 1- A E3
S 5504 PUSH SWITCH SPPH110300 N4090142 1- A F3
S 5505 PUSH SWITCH SPPH110300 N4090142 1- A D3
LED SPACER LH-3-13 S6000350 1-
LED SPACER LH-5-14 S6000387 1-
LED SPACER LH-5-10 S6000243 1-
Key Unit
Parts List
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS. LOT.REF. SIDE LAYADR
